3.8. ETHERNET
ZMC420SCAN bus galvanometer motion controller has a 100M network port, and it
supports MODBUS_TCP protocol and custom communication, the default IP address is
192.168.0.11. The pin definition is as follows:
The Ethernet port of the controller can be connected to a computer, HMI, etc. through
an Ethernet cable, and using point to point connection method. The schematic diagram
is as follows:
