Zmotion ZMC420SCAN - 3.12.1. DSCAN Interface Specification & Wiring

ZMC420SCAN Motion Controller Hardware Manual V1.5
11
X+
Galvanometer X channel signal +
12
Y+
Galvanometer Y channel signal +
13
NC
Reserved
14
STATUS+
Galvanometer state signal +
15
GND
Signal ground, public end
Note:
The local axis number 4/5 can be configured as the first galvanometer through
ATYPE=21, the local axis number 6/7 can be configured as the second galvanometer
through ATYPE=21, and the axis number can be changed through the AXIS_ADDRESS.
3.12.1. DSCAN Interface Specification & Wiring
→ Specification
Item
(CLK, SYN, X, Y, Z) ±
(STATUS) ±
Signal type
Differential output
Differential input
Electric level standard
0-5V TTL
Max communication velocity
10Mbps
Max current
± 20mA
+5mA
Isolation method
Non-isolation
→ Wiring Reference
