Zoom G1 Four User Manual

Using the tuner
Use this to tune the connected guitar.
Activating the tuner
1.
When using MEMORY, STOMP or EDIT mode, press and at the same time.
This activates the tuner.
HINT
Pressing anything other than
will close the tuner and return to the original screen.
Tuning a guitar
1.
Play the open string that you want to tune and adjust its pitch.
The display will differ according to the selected tuner type. (
“Changing tuner settings” on page
41)
CHROMATIC tuner
The nearest note name and pitch detuning will be shown on the display and by the LEDs.
When the pitch is accurate, the LED at the center of the meter will light green and the LEDs to the left
and right will light red.
Flat In tune Sharp
39

Zoom G1 Four Specifications

General

Best uses	Guitar
Product type	Expression pedal
Product color	Black
Power consumption	500 mA
Power source type	AC, Battery
Number of batteries supported	4
DC-in jack	Yes

Weight and Dimensions

Depth	156 mm
Width	130 mm
Height	42 mm
Weight	340 g
