Zoom G1 Four User Manual

Loading batteries
1.
Open the battery compartment cover on the bottom of the product and insert 4 AA batteries.
2.
Close the battery compartment cover.
NOTE
Set the type of battery used correctly so that the amount of remaining battery charge can be shown ac-
curately. (
“Setting the type of batteries used” on page 35)
HINT
• If a dedicated AC adapter (ZOOM AD-16) is connected, it can run on AC power.
• Power for operation can also be supplied through the USB port.
ECO mode overview
• By default, ECO mode setting is ON, so the power will automatically turn off if no use occurs for 10
hours.
•
ECO mode can also be set to “OFF” on the SETTING screen. (
“Setting the ECO mode” on page 36)
9

Zoom G1 Four Specifications

General

Best uses	Guitar
Product type	Expression pedal
Product color	Black
Power consumption	500 mA
Power source type	AC, Battery
Number of batteries supported	4
DC-in jack	Yes

Weight and Dimensions

Depth	156 mm
Width	130 mm
Height	42 mm
Weight	340 g
