Zoom G1 Four User Manual

Adjusting the torque
1.
Insert a 5 mm hex wrench into the torque adjustment screw on the side of the pedal.
2.
Turn it clockwise to tighten the pedal and counterclockwise to loosen it.
Loosen Tighten
NOTE
Be careful because loosening the torque adjustment screw too much could cause it to become discon-
nected internally, making it impossible to keep the pedal in a xed position.
55

Zoom G1 Four Specifications

General

Best uses	Guitar
Product type	Expression pedal
Product color	Black
Power consumption	500 mA
Power source type	AC, Battery
Number of batteries supported	4
DC-in jack	Yes

Weight and Dimensions

Depth	156 mm
Width	130 mm
Height	42 mm
Weight	340 g
