Zoom G2 FOUR User Manual

Changing tuner settings
The standard pitch used by the tuner and the tuner type can be changed. Flat tuning is also possible.
Setting the output method
Turn to set the output method.
Setting Explanation
BYPASS Effects are bypassed and the guitar sound is output.
MUTE The guitar sound is not output.
HINT:
Adjusting the EQ and volume of a guitar amp, for example, is easier if the G2 FOUR/G2X FOUR effects are
bypassed.
52

Zoom G2 FOUR Specifications

General

Rhythm Patterns	68
Simultaneous Effects	7
Sampling Frequency	44.1 kHz
A/D/A Conversion	24-bit
Rated Input Level	-20 dBu
Maximum Output Level	+5 dBu
Output Impedance	1 kΩ
USB Audio Interface	2 in / 2 out
Amp Models	22
Input	1/4" phone jack
Output	1/4" phone jack
Headphones	1/8" stereo phone jack
Power Supply	AA batteries or AC adapter
Frequency Response	20 Hz - 20 kHz
Input Impedance	470 kΩ
Expression Pedal	Yes
Inputs	1 x 1/4" (guitar)
Outputs	1 x 1/4"
Effect Types	79 (G2 FOUR) / 82 (G2X FOUR)
