Zoom R20 User Manual

❶
Guitars and basses
When directly connecting a guitar or bass with passive pickups, use INPUT 1 and set to ON.
When connecting a guitar or bass with active pickups or through an effect to the R20, use either INPUT
1 or 2. In this case, set to OFF when connecting to INPUT 1.
❷
Mics for lead and backing vocals, drums and other sound sources
Dynamic mics can be connected to INPUTS 3 and 4.
For INPUTS 5–8, set according to the type of mic connected.
• Dynamic mic: OFF
• Condenser mic: ON
❸
Headphones
❹
Powered monitors
12

Zoom R20 Specifications

General

Type	Digital Multitrack Recorder
Simultaneous Recording Tracks	8
Sample Rate	44.1 kHz
Bit Depth	24-bit
EQ	3-band EQ per channel
Inputs	8 XLR/TRS combo jacks
Phantom Power	+48V
Effects	Reverb, Chorus, Delay
Storage	SD card (up to 1TB)
USB	USB 2.0
Display	4.3-inch color touchscreen
Power Supply	AC adapter
Outputs	2 x TRS, 1 x Stereo Headphone
