Zoom R20 User Manual

Playing projects
1. Press .

Button operations during playback
• Search backward/forward: Press and hold /
• Move playback position forward/backward: Press /
• Stop: Press or .
• Return to beginning: Press when stopped
• Adjust track volume: Move channel fader
• Adjust master track volume: Move MASTER channel fader

Touchscreen operations during playback
• Zoom in/out horizontally:
Pinch in horizontally: Shorten the timeline
display
(This enables showing many bars at the same
time.)
Pinch out horizontally: Lengthen the timeline
display
(This enables displaying more detail.)
77

Zoom R20 Specifications

General

Type	Digital Multitrack Recorder
Simultaneous Recording Tracks	8
Sample Rate	44.1 kHz
Bit Depth	24-bit
EQ	3-band EQ per channel
Inputs	8 XLR/TRS combo jacks
Phantom Power	+48V
Effects	Reverb, Chorus, Delay
Storage	SD card (up to 1TB)
USB	USB 2.0
Display	4.3-inch color touchscreen
Power Supply	AC adapter
Outputs	2 x TRS, 1 x Stereo Headphone
