Zoom R20 User Manual

MIDI implementation chart
[Multi Track Recorder]
Model : R20
Date : Oct. 25, 2021
Version :1.00
Function ...
Transmitted Recognized Remarks
Basic
Channel
Default
Changed
x
x
1 - 16
x
C0 - E8
Mode
Default
Messages
Altered
x
x
****************** ******************
Mode 1
x
Note
Number
True voice
x
******************
0 - 127
24 - 124
Velocity
Note ON
Note OFF
x
x
o
x
After
Touch
Keyʼs
Chʼs
x
x
x
x
Pitch Bend
x x
Control
Change
x x
Program
Change
True Number
x
******************
x
******************
System Exclusive
x x
Common
Song Position
Song Select
Tune Request
x
x
x
x
x
x
System
Real Time
Clock
Commands
x
x
x
x
Aux
Messages
Local ON/OFF
All Notes OFF
Active Sense
System Reset
x
x
x
x
x
o
x
x
Notes
Mode 1 : OMNI ON, POLY
Mode 3 : OMNI OFF, POLY
Mode 2 : OMNI ON, MONO
Mode 4 : OMNI OFF, MONO
o : Yes
x : No
166

Zoom R20 Specifications

General

Type	Digital Multitrack Recorder
Simultaneous Recording Tracks	8
Sample Rate	44.1 kHz
Bit Depth	24-bit
EQ	3-band EQ per channel
Inputs	8 XLR/TRS combo jacks
Phantom Power	+48V
Effects	Reverb, Chorus, Delay
Storage	SD card (up to 1TB)
USB	USB 2.0
Display	4.3-inch color touchscreen
Power Supply	AC adapter
Outputs	2 x TRS, 1 x Stereo Headphone
