❶
DC 5V port (Type-C)
Use this power supply USB port to connect an AC adapter or portable battery. (→ Using an external
power supply)
❷
USB port (Type-C)
Use this USB port to connect with a computer or iOS/iPadOS device. (→ Connecting to computers,
Connecting to iOS/iPadOS devices)
❸
MIDI jacks
Use these to connect external MIDI equipment.
• OUT connector: Connect the MIDI IN connector of an external MIDI device here.
• IN connector: Connect the MIDI OUT connector of an external MIDI device here.
❹
OUTPUT jacks
These output the left (L) and right (R) channels of a stereo signal. Connect these to speakers with built-
in amplifiers, for example.
