Connecting instruments and mics
Always set and to their minimum values and turn off before connecting instruments
and mics.
The UAC-232 adjusts the gain (amplification) of input signals according to their sources to raise them to
levels that are easy to work with. The default gain amounts are as follows.
Input source Gain
Dynamic mic (phantom power off) +45 dB
Condenser mic (phantom power on) +27 dB
Line (GUITAR/BASS off) +24 dB
Guitar/bass (GUITAR/BASS on) +18 dB
NOTE:
• Gain settings can be changed by using ZOOM UAC-232 Mix Control. (→ Using ZOOM UAC-232 Mix
Control)
• With 32-bit float recording, recording quality will not be degraded by gain settings.
20
