Headphones 44.1 kHz: 20 Hz – 20 kHz, +0.0 dB /
−0.5 dB
192 kHz: 20 Hz – 80 kHz, +0.0 dB /
−1.0 dB
Equivalent input noise –127 dBu or less (IHF-A)
Input and output
channels
Recording: 2 channels
Playback: 2 channels
Sampling frequencies 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz,
176.4 kHz, 192 kHz
Bit depth 32-bit float / 24-bit
Interface USB 2.0
Audio interface
Class USB Audio Class 2.0
Power AC adapter (ZOOM AD-17): DC 5 V/1
A
• USB bus power is supported.
Rated current USB / AC adapter (5 V): 293 mA
Power consumption 5 W maximum
Dimensions 164 mm (W) × 105.5 mm (D) × 65
mm (H)
Weight (unit only) 355 g
Note: 0 dBu = 0.775 Vrms
