RT100 Rough Terrain Crane
(3) Install and remove the outrigger floats.
Before you extend the outriggers, remove the socket pin from the outrigger
floats and pull out the outrigger floats. When the hole aligns with the vertical
cylinder, install the socket pin.
After you fully retract the outriggers, remove the socket pin and push in the
outrigger float until it in the correct position. Install the socket pins.
Before you move the outriggers, make sure that there is clearance to
prevent injury to personnel or damage to the crane and other objects.
Do not move the outriggers if you have a load off the ground.
You can adjust the speed (slow or fast) of the outriggers movement
(extend or retract) by the engine RPM (increase or decrease).
Make sure that you install the outrigger floats before you move the
Make sure that you remove the retaining pins before you extend or
retract the outrigger beams. After the outrigger beams are in position,
install the retaining pins.
Before you extend or retract the outriggers, make sure that the floats
are clear from all objects.
Make sure that all the tires are off the ground (crane weight held up by
the outriggers) before you start to lift a load.
When the crane is on a level area, examine the bubble indicator. The
bubble shows in the middle of the indicator. If not, adjust the nuts
