9-14 RT100RoughTerrainCrane
(3)Outriggerboxesaredirectlyweldedontothecranechassis.
(4)Youcanfullyandintermediatelyextendandfullyretracttheoutriggersforcrane
operation.
Outriggerspread(L):26.2ft(8000mm)
Outriggerspread(W):
Fullyextend: 25.9ft(7900mm)
Intermediatelyextend: 18.2ft(5540mm)
Fullyretract: 10.4ft(3180mm)
