RT100RoughTerrainCrane 9-15
SPECIFICATIONS-SPECIALPURPOSECHASSISFORROUGHTERRAINCRANE
A. Type
(1)Rear-mountedengine,left-handdrivetype
(2)Drivemode:4x2and4x4
B. ChassisFrame
High-tensilesteel,weldedintegralbox-typeconstruction
C. Engine
(1)Model
CUMMINSQSC8.3
(2)Type
Fourstrokecycles,6-cylinderin-line,electronjet,water-cooled,turbocharged
(3)Performance
Max.outputpower: 300BHP(224KW)/2200RPM
Max.outputtorque: 1000lb-ft(1356Nm)/1500RPM
D. Drivesystem
(1)Electricallycontrolledautomatichydraulictransmission,withtwomodes:2-wheel
driveand4-wheeldrive.
(2)Severalforwardandreversegears,electro-hydraulicpowershift,andautomatic
lockingmechanism.
(3)Theengineandtransmissionsupplythepowertodrivethehydraulicoilpumpand
steeringsystem.
E. Axle
(1)Frontaxle
Steeranddriveaxle,rigidlyattachtothechassisframe,withplanetaryreducer
andbrakes.
(2)Rearaxle
Full-floatsteeranddriveaxle,withplanetaryreducerandbrakes.
F. Steeringsystem
(1)Fullhydraulicpowersteeringgear
(2)Thesteering-wheelcontrolsthecylindertoturnthewheels.
(3)Foursteeringmodes:
2-wheelsteer – frontwheelsteer
2-wheelsteer – rearwheelsteer
