9-16 RT100RoughTerrainCrane
4-wheelsteer – all-wheelsteer
4-wheelsteer – crabsteer
G. Suspensionsystem
(1)Frontaxle:rigidlymountedtothecranechassis
(2)Rearaxle:Oscillationautomaticallylocksifsuperstructureisswungmorethan3
degreespastboomoverthefront.Oscillationalsolockswhenparkingbrakeis
engaged.
H. Brakesystem
(1)Servicebrake
Hydraulicallycontrolleddiscbrakesonfourwheels
(2)Parkingbrake
Springapplied,hydraulicallyreleasedparkingbrakeismountedtotheinputshaft
ofthefrontaxle.
I. Electricalsystem
24VoltDC
2batterieswith12Vratedvoltageand120Ahratedcurrent.
J. Fueltank
Capacity: 79gal(300L)
K. Tire
Size: 29.5R29☆☆
SAFETYDEVICES
l RatedCapacityIndicator(RCI)
l RotatingBeaconandHorn
l Anti-TwoBlockDevices
l 3
rd
Wrap
l BalanceValve
l HydraulicLock
l HydraulicSafetyValve
l SwingBrake
l SwingLockoutDevice
l BoomAngleIndicator
l OutriggerBeamRetainingPin
