06 - 14 RT100 Rough Terrain Crane
Free swing – Push to operate the FREE SWING. Push again to release this function.
(Located on right side of joystick)
Free
Swing
Figure 06 – 10 Right Joystick (Boom Hoist / Main Winch Control)
Note
Only when the operator’s seat is
occupied and the icon on the
display lights up, the joysticks can initiate various movements.
