RT100 Rough Terrain Crane 06 - 13
The spray of washer fluid stops after 15 seconds or if the washer fluid
tank is empty. Do not operate the wipers on hot sunny days unless you
use spray the window with wiper fluid. When the temperature is below
freezing, make sure that the wiper blades are not stuck to the window
before you set the wipers to ON.
5. BRAKE PEDAL – Push the brake pedal to decelerate or stop the crane.
6. IGNITION SWITCH – The 4 positions of the switch are as follows:
 “I” – Media player is ON.
 “II” – All circuits, this does not include the starter, are ON.
 "III" - A temporary position, use it to operate the starter
 "O" - All circuits are OFF.
Note
Make sure that you release the ignition ("III" position) when the engine starts.
Caution
You cannot remove the key from the ignition until the switch is in the
"O" position (OFF).
7. THROTTLE PEDAL – Push the pedal to increase the engine RPM, release the pedal
to decrease it. The movement of the items that follow can increase or decrease as the
speed of the engine changes:
 Boom swing
 Increase or decrease the angle of the boom
 Extend or retract the boom
 Hoist movements (raise or lower a load).
Note
You can use the throttle pedal with the joysticks and boom extend / retract
pedal to increase / decrease the speed of the items in (7).
8. HAND THROTTLE – Used with the Hand / Foot Throttle Select Switch to increase
or decrease the engine RPM.
9. BUBBLE LEVEL – You use this to make sure that the crane is level.
10. BOOM HOIST / MAIN WINCH CONTROL - Move the joystick forward to reel-off main
winch rope. Move the joystick rearward to spool-up main winch rope. Move the
joystick left to lift the boom. Move the joystick right to lower the boom.
Horn – Push and hold-in to make a sound. (Located on left side of joystick).
