Zte ZXR10 5250 Series - VBAS Configuration; Figure 5-34 VBAS Typical Network

ZXR105250SeriesCongurationGuide
5.29VBASConguration
VBASOverview
TheVirtualBroadbandAccessServer(VBAS)isnotphysicalequipmentbutaprotocol
standard,whichisdevelopedbyChinaTelecom.TheVBASisusedtosolvetheproblem
ofwide-banduseridentier.WhentheBroadbandAccessServer(BAS)getsuser
identierbyinquiringcorrespondingrelationshipbetweenMACofusersdialingtothe
switchandport,thensendsusername,passwordandidentierinformationtoRADIUS,it
candeterminethepositionoftheuser.
Layer2communicationmodeisimplementedbetweenBASandswitches,thatis,
informationqueryandresponsedatapacketsofVBASareencapsulatedintoEthernet
dataframesoflayer-2directly,anduseprotocolnumber0x8200foridentication.
Note:
OnlytrustportscanreceiveVBASpacketsandVBASresponsepacketsonlycanbesent
fromtrustports.
PortconnectingtousernetworkiscalledcascadeportandportconnectingtoBASserver
iscalledtrustport.ForthetypicalnetworkofVBAS,seeFigure5-34.
Figure5-34VBASTypicalNetwork
ConguringVBAS
TheVBAScongurationincludesthefollowingcommands:
CommandFunction
zte(cfg)#setvbastrust-port<portlist>{enable|disable}Enablesordisablestheglobal
VBAStrust-port.
