ZXR105250SeriesCongurationGuide
Figure6-32MirrorInformationPage
Thispagedisplaysthefollowinginformation:
ParameterDescription
SourceportMirroringsourceport
DestinationportMirroringdestinationport
PortMirroringConguration
ClickConguration>MIRROR>MirrorCongureontheleftofthemainpage.The
mirroringportcongurationpageisdisplayed,seeFigure6-33.
Figure6-33MirroringPortCongurationPage
Thesourceportanddestinationportcanbeconguredonthispage.Aftersetting,
clickApplytocompletetheconguration.
lLACPManagement
6-40
