CommandFunction
showlacp(allcongurationmodes)DisplaystheLACPglobal
congurationinformation.
showlacpaggregator(allcongurationmodes)Displaysbriefinformationofall
LACPaggregationgroups.
showlacpaggregator<1-15>(allcongurationmodes)Displaysdetailedinformationofan
LACPaggregationgroup.
showlacpport(allcongurationmodes)Displaysaggregationstatus
informationofalltheLACP
memberports.
showlacpport[<portlist>](allcongurationmodes)Displaysaggregationstatus
informationofLACPmember
ports.
zte(cfg)#cleartrunk<trunklist>{multicast-filter}Clearstheagoftheportmulticast
lter.
LACPCongurationInstance
lCongurationDescription
SwitchAandswitchBareconnectedthroughtheaggregationport(bindingtheport
15andport16).Port1ofswitchAandport2ofswitchBbelongtoVLAN2.Port3of
switchAandport4ofswitchBbelongtoVLAN3.MembersofthesameVLANcan
communicatewitheachother.SeeFigure5-3.
Figure5-3LACPCongurationInstance
lCongurationProcedure
1.ThedetailedcongurationofswitchAisasfollows:
zte(cfg)#setlacpenable
zte(cfg)#setlacpaggregator3addport15-16
zte(cfg)#setlacpaggregator3modedynamic
zte(cfg)#setlacpload-balancepacketL2
5-18
