Chapter5ServiceConguration
1.Intheinitialstate,boththeprimarylinkandthesecondarylinkoperateproperly.Then
ZESSblocksthesecondarylinkandusestheprimarylinkfordataforwarding.
2.Whentheprimarylinkisdisconnected,ZESSrapidlyswitchesthesecondarylinkto
Forwardingstateandblockstheprimarylink.
3.Whentheprimarylinkrecoversfromdisconnection,ifreversalmodeisenabled,ZESS
willsettheprimarylinktoForwardingstateandblocksthesecondarylink;ifnon-re-
versalmodeisenabled,ZESSwillblocktheprimarylinkandcontinuestousethe
secondarylinkfordatatransmission.
Note:
Inreversalmode,whentheprimarylinkrecoversfromdisconnection,thelinkisnot
switchedimmediatelybutafteraperiodofthepreuptime.
ConguringZESS
TheZESScongurationincludesthefollowingcommands:
StepCommandFunction
1ZXR10(config)#setzessdomain<1-4>
protect-instance<1-16>primary{port
<port-name>|trunk<trunk-name>}secondary
{port<port-name>|trunk<trunk-name>}
CreatesaZESSdomain.
ThecontrolVLANmustbeelectedfrom
idleVLANs.Itcannothaveanyconictwith
serviceVLANsorNetworkManagement
VLANs.
2ZXR10(config)#setzessdomain<1-4>mode
{revertive|non_revertive}
CongurestheZESSswitchingmode.The
defaultvalueisreversalmode.
HerearetwoZESSswitchingmodes:
lRevertive:reversalmode.
lNon_revertive:non-reversalmode.
3ZXR10(config)#setzessdomain<1-4>
ctrl-vlan<1-4094>
ConguresthecontrolVLAN.
4ZXR10(config)#setzessdomain<1-4>
preup<1-600>
Conguresthepreuptime(s).Default:5.
Thepreuptimeisusedinreversalmode.
Intheconditionthattheprimarylinkis
disconnectedandthesecondarylinkisin
usefordataforwarding,iftheprimarylink
recoversfromdisconnection,ZESSdoes
notswitchthedatatrafctotheprimary
linkimmediately.Itwaitsforthepreup
timebeforeitimplementstheswitching,to
preventtheswitchingfromoccurringwhen
theprimarylinkrecoveryisstillunstable.
5-123
