Chapter 13 VPN
P-79X Series User’s Guide
146
13.6.9.1 ID Type and Content Examples
Two IPSec routers must have matching ID type and content configuration in order to set up a VPN
tunnel.
The two P-79Xs in this example can complete negotiation and establish a VPN tunnel.
The two P-79Xs in this example cannot complete their negotiation because P-79X B’s Local ID
type is IP, but P-79X A’s Peer ID type is set to E-mail. An “ID mismatched” message displays in
the IPSEC LOG.
E-mail Type an e-mail address (up to 31 characters) by which to identify this P-79X.
The domain name or e-mail address that you use in the Content field is used for
identification purposes only and does not need to be a real domain name or e-
mail address.
Table 54 Peer ID Type and Content Fields
PEER ID TYPE= CONTENT=
IP Type the IP address of the computer with which you will make the VPN connection
or leave the field blank to have the P-79X automatically use the address in the
Secure Gateway Address field.
DNS Type a domain name (up to 31 characters) by which to identify the remote IPSec
router.
E-mail Type an e-mail address (up to 31 characters) by which to identify the remote
IPSec router.
The domain name or e-mail address that you use in the Content field is used for
identification purposes only and does not need to be a real domain name or e-
mail address. The domain name also does not have to match the remote router’s
IP address or what you configure in the Secure Gateway Address field below.
Table 53 Local ID Type and Content Fields
LOCAL ID TYPE= CONTENT=
Table 55 Matching ID Type and Content Configuration Example
P-79X A P-79X B
Local ID type: E-mail Local ID type: IP
Local ID content: tom@yourcompany.com Local ID content: 1.1.1.2
Peer ID type: IP Peer ID type: E-mail
Peer ID content: 1.1.1.2 Peer ID content: tom@yourcompany.com
Table 56 Mismatching ID Type and Content Configuration Example
P-79X A P-79X B
Local ID type: IP Local ID type: IP
Local ID content: 1.1.1.10 Local ID content: 1.1.1.10
Peer ID type: E-mail Peer ID type: IP
Peer ID content: aa@yahoo.com Peer ID content: N/A
