Viewable distance means maximum range of the optimum standard
3 OPERATION
3.1 STATUS INDICATORS
3.1.1 IGNITION LED
This LED is to notify the operator that the vehicle’s ignition has been turned on which will then turn on
the DVR. This LED will be blinking when ignition is turned on and until DVR powers on. This LED will also blink
very quickly when ignition is turned off and until DVR powers off completely.
3.1.2 POWER LED
This LED is to notify operator that system power is on.
3.1.3 ERROR LED
This LED is to notify operator that the system has encountered a problem and cannot continue normal
operation when lit solid. Please call tech support for troubleshooting procedures.
Error LED indication for USB retrieval. When using USB retrieval to retrieval the GPS data or Lock video
files, the Err Led will flash at the speed of 500ms on and 500ms off. If the Err led flash, the USB stick is not ready
to remove
3.1.4 VIDEO LOST INDICATOR LED
This LED is to notify operator when any of the enabled cameras loses video signal meaning the cable is
cut, not connected or the camera is having a problem.
3.1.5 RECORD LED
This LED indicates if the DVR is recording.
3.1.6 HDD ON/OFF LOCK
The HDD On/Off lock mechanism is employed to prevent unauthorized operators from removing the
media storage and tampering with video data. Turn the key to position “Close” to lock media storage or “Open”
to unlock. The ZEUS will NOT record video if the lock mechanism is in the “Open” position
3.1.7 MEDIA STORAGE REMOVAL
The media storage is hot swappable and can be removed and inserted without turning the ignition of
the vehicle off. This process will take roughly 10 to 20 seconds to complete. The feature is helpful when access
to video is needed but vehicle is still running its’ route. User can remove the media storage and insert a new
one so that the needed video can be retrieved right away.
1. Turn key to the “Open” position:
