4.2 CONNECT CROSS-OVER CABLE
During installation the DVR can be connected to a laptop allowing the installer to preview the cameras for
aiming purposes. Using the grey cross-over cable shipped with the DVR, attach one end to the DVR port labeled
LAN and the other end to the LAN port on the laptop. To verify the correct cable is used check the end of the
cable for the “XOVER” label. Note: A patch cable (standard network cable) will not work.
4.3 SETTING UP YOUR PC
4.3.1 USING WINDOWS XP
3.1.4.1. Right click on My Network Places
3.1.4.2. Go to Properties and left click
3.1.4.3. Right click on Local Area Connection
3.1.4.4. Go to Properties and left click
3.1.4.5. Left click on Internet Protocol (TCP/IP)
3.1.4.6. Left click on Properties
3.1.4.7. Record ANY numbers on this screen for your record if needed
3.1.4.8. Left click on Use the following IP Address button
3.1.4.9. In the IP address window type 192.168.1.55
3.1.4.10. Left click mouse on Subnet mask and you should have 255.255.255.0
3.1.4.11. There should be no other numbers in the TCP/IP properties
3.1.4.12. Left click on OK or Close
4.3.2 USING WINDOWS VISTA
3.1.4.13. Right click on the Network icon on the desktop
3.1.4.14. Go to Properties and left click
3.1.4.15. Find Manage network connections under Tasks and left click
3.1.4.16. Right click on Local Area Connection
3.1.4.17. Go to Properties and left click
3.1.4.18. Message appears asking permission to continue, left click to continue
3.1.4.19. Left click on Internet Protocol Version 4 (TCP/IPv4)
3.1.4.20. Then left click on Properties
3.1.4.21. Record ANY numbers on this screen for your records if needed
3.1.4.22. Left click on Use the following IP Address button
3.1.4.23. In the IP address window type 192.168.1.55
3.1.4.24. Left click on Subnet mask and you should have 255.255.255.0
3.1.4.25. There should be no other numbers in the TCP/IP properties
3.1.4.26. Left click on OK or Close
Note:
If the steps in setting up your PC do not work, contact you IT department concerning your PC, this is a one-time
setup.
4.3.3 USING WINDOWS 7
3.1.4.27. Click on the Start button in the lower left corner
3.1.4.28. Select control panel
3.1.4.29. Select and open Network and Sharing center
3.1.4.30. Select Change adapter settings
