This option is enabled then HDD removable disk have to replace with HBD removable disk. Refer item
3.7 for more detail about HBD disk Operation.
4.8.20 SCREEN NUMBER
This can be set at 1 or 4, if set at 1 it will display camera input 1 via the RCA video out port on the front
of the DVR. If 4 is selected it will display a QUAD view and include all 4 camera inputs via the RCA video out
port.
4.8.21 DRIVE-SAFE (G-FORCE SET-UP)
If the TAB101 option is checked as listed above, the G-Force parameters will then appear on the system
set-up page after a system re-boot. NOTE: DO NOT CHANGE ANY OF THE BASE, PEAK OR CRASH VALUES.
The only values to possibly change are those associated with the UPLOAD. The Upload process works in
conjunction with the WIFI Touchdown system, systematically uploading 30 seconds of video pre & post if the G-
Force trigger point meets or exceeds the value in the Upload column for the associated trigger. G-Force data
values work with the GPS MiniTRACK option to be displayed in a text report or on a map. See the Drive-Safe™
manual for further clarification.
