The controls and buttons in the main screen:
No Name Description
1 Play Brings up these options: Live View, Play Archive, Play File
2 Disconnect Disconnects DVRViewer from a DVR or from a media storage
3 Setup Enters DVR setup
4
Users
Enables user to create, delete and modify users
5 Quick Clip
Creates 1 minute video file 30 seconds before selected time to 30
seconds after
6 Snap Shot Creates a single frame jpeg picture file
7 Start Time
Sets the start time automatically based on the current cursor timeline
position
8 End Time
Sets the start time automatically based on the current cursor timeline
position
9 Make Clip
Creates a custom video clip starting from the start time and end time
entered
10 Start Time Let’s user manually set the start time
11 End Time Let’s user manually set the end time
12 Calendar Displays current month calendar of video playback
13
Date & Time
Displays current date & time of video playback
14
Previous
Goes back one hour or day as set below
15 Slider Bar Time Range
Switches between One Day View, One Hour View or 15 Minute View
during playback
16 Next Advances one hour or day as set above
17 Slow Slows down playback speed
18
Jump Backward 20
Seconds
Jumps backwards video playback 20 seconds
19
Pause / Play
Pauses or plays video playback
20
Jump Forward 20
Seconds
Jumps forward video playback 20 seconds
21
Fast
Accelerates playback speed
22
One Frame Forward
Advances one frame forward while in Pause mode during playback
23 Start / Stop MiniTRACK
Starts or stops the connection to the MiniTRACK server. An Internet
connection is needed for this connection. To use this feature you must
purchase the Video-Track option
24
Audio All
Channels/Single Channel
Switches audio playback from all channels simultaneously or a single
channel
25
Volume Control
Slider Bar to control volume from 0 (Mute) to 100
