1-25
z After RSA key pairs are generated, the display rsa local-key-pair public command displays two
public keys (the host public key and server public key) when the switch is working in
SSH1-compatible mode, but only one public key (the host public key) when the switch is working in
SSH2 mode.
z The results of the display rsa local-key-pair public command or the public key converted with the
SSHKEY tool contains no information such as the authentication type, so they cannot be directly
used as parameters in the public-key peer command. For the same reason, neither can the results
of the display public-key local rsa public command be used in the rsa peer-public-key command
directly.
SSH Configuration Examples
When Switch Acts as Server for Local Password Authentication
Network requirements
As shown in Figure 1-11, establish an SSH connection between the host (SSH Client) and the switch
(SSH Server) for secure data exchange. The host runs SSH2.0 client software. Password
authentication is required.
Network diagram
Figure 1-11 Switch acts as server for local password authentication
Configuration procedure
z Configure the SSH server
# Create a VLAN interface on the switch and assign an IP address, which the SSH client will use as the
destination for SSH connection.
<Switch> system-view
[Switch] interface vlan-interface 1
[Switch-Vlan-interface1] ip address 192.168.0.1 255.255.255.0
[Switch-Vlan-interface1] quit
Generating the RSA and DSA key pairs on the server is prerequisite to SSH login.
