4-6 CHAPTER 4: CONFIGURING THE 3C509B NIC
Configuration Option Settings
Table 4-1 lists each software option, the default setting,
and the available settings. For more information about
each setting, select the option and press [F1]).
.
If you are using a PC that supports Plug and Play, the IRQ
and I/O base address values are set by Plug and Play. You
can set the boot PROM size to indicate the presence and
size of a network boot PROM.
To disable Plug and Play at the DOS command line, type:
3C5X9cfg configure /pnp:n [Enter]
You can also type:
pnpdsabl.bat [Enter]
Table 4-1 Option Settings
Option Default Setting Available Settings
I/O Base Address 300h 200h, 210h, 220h, 230h, 240h, 250h,
260h, 270h, 280h, 290h, 2A0h, 2B0h,
2C0h, 2D0h, 2E0h, 2F0h, 300h, 310h,
320h, 330h, 340h, 350h, 360h, 370h,
380h, 390h, 3A0h, 3B0h, 3C0h,
3D0h, 3E0h, EISA, ISA
Interrupt
Request Level
10 3, 5, 7, 9, 10, 11, 12, 15
Boot PROM Disabled. Does not
apply for
3C509B-TPO
Disabled, 8 K, 16 K, 32 K
Transceiver Type Auto Select for all
except
3C509B-TPO
(on-board TP)
On-board Coax (BNC), On-board TP
(RJ-45), External (AUI/DIX), or Auto
Select
Network Driver
Optimization
Windows or OS/2
Client
DOS Client, Windows or OS/2 Client,
Server
Maximum
Modem Speed
(fastest modem
installed)
9600 Baud No Modem, 1200, 2400, 9600, 19200,
or 38400 Baud
Plug and Play Enabled Enabled, Disabled
Full Duplex Disabled Enabled, Disabled
