2.4 Hardware Installation
Please follow the steps mentioned below to install the hardware of EAP200:
1. Place the EAP200 at the best location.
The best location for EAP200 is usually at the center of your intended wireless network.
2. Connect the EAP200 to your network device.
Connect one end of the Ethernet cable to LAN port of EAP200 and the other end of the cable to a
switch, a router, or a hub. EAP200 is then connected to your existing wired LAN network.
3. There are two ways to supply power over to EAP200.
a) Connect the DC power adapter to the EAP200 power socket.
b) EAP200 LAN port is capable of transmitting DC currents. Connect an IEEE 802.3af-compliant
PSE device (e.g. a PoE-switch) to the LAN port of EAP200 with the Ethernet cable.
Now, the Hardware Installation is complete.
• Please only use the power adapter supplied with the EAP200 package. Using a different
power adapter may damage this system.
• To double verify the wired connection between EAP200 and you switch / router / hub, please
also check the LED status indicator of the respective network devices.
