Managing the Radio | 111
Aprisa SRx User Manual 1.3.0
Ethernet > Port Setup
This page provides the setup for the Ethernet ports settings.
ETHERNET PORT SETTINGS
Mode
This parameter controls the Ethernet traffic flow. The default setting is Standard.
Option
Function
Standard
Enables Ethernet data communication over the radio link but
Ethernet traffic is not switched locally between the two
Ethernet ports.
Switch
Ethernet traffic is switched locally between the two
Ethernet ports and communicated over the radio link
Disabled
Disables all Ethernet data communications.
Speed (Mbit/s)
This parameter controls the traffic rate of the Ethernet port. The default setting is Auto.
Option
Function
Auto
Provides auto selection of Ethernet Port Speed
10/100 Mbit/s
10
The Ethernet Port Speed is manually set to 10 Mbit/s
100
The Ethernet Port Speed is manually set to 100 Mbit/s
