56 | Installing the Radio
Aprisa SRx User Manual 1.3.0
Rack Shelf Mounting
The Aprisa SR can be mounted on a rack mount shelf using the four M4 threaded holes in the Aprisa SR
enclosure base. The following picture shows Aprisa SR mounted on a 1 RU rack mounted shelf.
4RF SR+ Acc, Mounting, 19" Rack Mount Shelf, 1U
WARNING:
If the Aprisa SR is operated in an environment where the ambient temperature
exceeds 50°C, the Aprisa SR convection air flow over the heat sinks must be
considered.
