4RF Aprisa SR - General Specifications; Environmental; Mechanical

Specifications | 319
Aprisa SRx User Manual 1.3.0
General Specifications
Environmental
Operating temperature range
-40 to +70˚ C (-40 to +158˚ F)
Storage temperature range
-40 to +80˚ C (-40 to +176˚ F)
Operating humidity
Maximum 95% non-condensing
Acoustic noise emission
No audible noise emission
Mechanical
Aprisa SR Radio
Dimensions
Width 210 mm (8.27”)
Depth 130 mm (5.12”) and 146 mm (5.748”)
with TNC connectors
Height 41.5 mm (1.63”)
Weight
1.25 kg (2.81 lbs)
Colour
Matt black
Mounting
Wall (2 x M5 screws)
Rack shelf (2 x M4 screws)
DIN rail bracket
Aprisa SR Protected Station
Dimensions
Width 432.6 mm (17”)
Depth 372 mm (14.6”) and 388 mm (15.276”)
with TNC connectors
Height 2U plus external duplexer (if used)
Weight
12 kg (27 lbs) (includes the 2 radios)
Colour
Matt black
Mounting
Rack mount (2 x M6 screws)
