4RF Aprisa SR - Transmitter

312 | Specifications
Aprisa SRx User Manual 1.3.0
Transmitter
Average Power output
QPSK
0.01 to 5.0 W (+10 to +37 dBm, in 1 dB steps)
Note: The Peak Envelope Power
(PEP) at maximum set power
level is +41 dBm.
Note: The Aprisa SR transmitter contains power amplifier protection which allows the antenna to be
disconnected from the antenna port without product damage.
Adjacent channel power
< - 60 dBc
Transient adjacent channel power
< - 60 dBc
Spurious emissions
< - 37 dBm
Attack time
< 1.5 ms
Release time
< 0.5 ms
Data turnaround time
< 2 ms
Frequency stability
± 1.0 ppm
Frequency aging
< 1 ppm / annum
