Aprisa SRx User Manual 1.3.0
This page displays the current radio RF receive path parameters from single or multiple source radios that
the radio is receiving from.
The results shown are since the page was opened and are updated automatically every 12 seconds.
RADIO PARAMETERS
The source Node Address of the radio receiving data from.
The RSSI of the RF signal received from the source radio/s.
The SNR of the RF signal received from the source radio/s.
The frequency difference between this radio’s receiver and the
frequency of the incoming packet rate from the source radio/s.
The current radio receive modulation being used to communicate
with the source radio/s.
The timestamp of the last received packet from the source
radio/s.
Controls
The Next button will display the next page of 8 radios and the Prev button will display the previous page
of 8 radios.
