Data to be Sent.
00100
3
Count data sent.
You select which data to be sent by keying in a
0 or 1 for the data: Date, ID no., PCS
(count), weight or unit weight.
Example: Key in 0 1 1 0 0 to
display 01100, this setting would send only the ID
number and the count.
f-X-02
06
07
08
00000
Weight
PCS(count)
Date/Time Unit
ID Weight
Data Format
0
3
Format for AD-8121 MODE 1.
1
Format for AD-8121 MODE 3.
No difference between “0”
and ”1” when used with the
UFC format.
2
Format for general apparatuses, computers, etc.
f-X-03
06
07
08
Baud Rate
0
3
2400 bps.
1
4800 bps.
2
9600 bps.
f-X-04
06
07
08
Data Length and Parity
0
3
7 bits, even parity.
1
7 bits, odd parity.
2
8 bits, non parity.
f-X-05
06
07
08
41
To Next Page
