A&D FC-5000Si - 14 Specifications

6. Go to step 2 in section “9-1. Calibration Procedure Using a Weight”
to calibrate the remote scale.
14. SPECIFICATIONS
MODEL FC-500 i FC-1000 i FC-2000 i FC-5000 i FC-10K i FC-20K i FC-50K i
Capacity (k)g 500 g 1 kg 2 kg 5000 g 10 kg 20 kg 50 kg
Resolution (k)g 0.05 g 0.1 g 0.2 g 0.5 g 1 g 2 g 5 g
Capacity lb 1 lb 2 lb 5 lb 10 lb 20 lb 50 lb 100 lb
Resolution lb 0.0001 lb 0.0002 lb 0.0005 lb 0.001 lb 0.002 lb 0.005 lb 0.01 lb
Sample Size 10 pieces normal – 5, 25, 50, 100 or random number, user selectable
Min. Unit Weight
(Normal mode)
0.01 g 0.02 g 0.04 g 0.1 g 0.2 g 0.4 g 1 g
Min. Unit Weight
(Fine mode)
0.0005 g 0.001 g 0.002 g 0.005 g 0.01 g 0.02 g 0.05 g
Non-linearity ±0.05 g ±0.1 g ±0.2 g ±0.5 g ±1 g ±2 g ±5 g
Repeatability 0.05 g 0.1 g 0.2 g 0.5 g 1 g 2 g 5 g
Span Drift 0.002%/°C (5°C~35°C) typ.
Operating Temp. -10°C to 40°C/14°F to 104°F, less than 85%R.H. (No Condensation)
Display 7 segment / 5x7 dot VFD
Display Update Approximately 10 times per second
Interface RS-232C (1ch.) standard, Maximum 3 ch. with optional interface
Power
AC adapter or Optional Ni-MH Battery Pack
Battery Operating Time: Approx. 10 hours (main scale only)
Platform Size
205 x 152 (mm)
8.1 x 6.0 (inches)
315 x 270 (mm)
12.4 x 10.6 (inches)
Dimensions
(W) x (D) x (H)
330 x 462 x 107 mm
13.0 x 18.2 x 4.2 inches
330 x 462 x 117 mm
13.0 x 18.2 x 4.6 inches
Weight (approx.) 5.5 kg 5.5 kg 6.5 kg 6.7 kg 6.7 kg 6.7 kg 7.5 kg
Calibration Weight
500 g ±
0.01 g
1 kg ±
0.02 g
2 kg ±
0.05 g
5kg±0.1g 10kg±0.2g 20kg±0.5g 50kg±1g
Accessories This manual, AC adapter
73
