MODEL FC-500S
i
FC-5000S
i
Capacity g 500 g 5000 g
Resolution g 0.02 g 0.2 g
Capacity lb 1 lb 10 lb
Resolution lb 0.00005 lb 0.0005 lb
Sample Size 10 pieces normal – 5, 25, 50, 100 or random number, user selectable
Min. Unit Weight
(Normal mode)
0.001 g 0.01 g
Min. Unit Weight
(Fine mode)
0.00005 g 0.0005 g
Non-linearity ±0.02 g ±0.2 g
Repeatability 0.02 g 0.2 g
Span Drift 0.001%/°C (5°C~35°C) typ.
Operating Temp. 5°C to 40°C/41°F to 104°F, less than 85%R.H. (No Condensation)
Display 7 segment / 5x7 dot VFD
Display Update Approximately 10 times per second
Interface RS-232C (1ch.) standard, Maximum 3 ch. with optional interface
Power
AC adapter or Optional Ni-MH Battery Pack
Battery Operating Time: Approx. 10 hours (main scale only)
Platform Size 128 x 128 (mm)/ 5.0 x 5.0 inches 165 x 165 (mm) / 6.5 x 6.5 inches
Dimensions
(W) x (D) x (H)
330 x 462 x 106 mm
13.0 x 18.2 x 4.2 inches
Weight (approx.) 7.6 kg 8.1 kg
Calibration Weight 500 g ± 0.005 g 5000 g ± 0.05 g
Accessories This manual, AC adapter
Options
OP-01 Bar Code Reader
OP-02 Ni-MH Battery Pack
OP-03 RS-232C x 2ch. (Confirm the following note)
OP-04 RS-232C x 1ch. + Comparator Relay output (Confirm the following note)
OP-05 Remote Scale Interface
Note OP-03 and OP-04 can not be installed at the same time.
74
