Page 24
Use of the cuff cover
Step 1 Pass the air hose through the slit.
Step 2 Place the cover on the cuff as shown. Link them using the three velcro strips.
Attaching the cuff and recorder
Caution
If the cuff is not attached at the right position, the recorder may not measure
the blood pressure correctly and an error may occur.
The cuff accessory is for use on the left arm, of about 20cm ~ 31cm. If you
need a different cuff, purchase a cuff of the proper size and arm position. Refer
to "Option and Accessories".
Do not use, if the patient has dermatitis, etc.
Keep the cuff clean. Exchange the cuff cover for each patient. The cuff cover
may be used for both right or left.
Steps for attaching the cuff and recorder
Step 1 Make a circle where the end of the cuff is passed through the ring.
Step 2 Search for the brachialis artery using palpation.
Velcro
Velcro
Velcro
Slit for air hose
Left arm cuff
Right arm cuff
Slit for air hose
Cuff cove
