Data Transfer
The recorder transfers data to a printer or computer using the RS-232C terminal.
We recommend analysis of the data using the optional analysis software.
Caution
Cap the RS-232C terminal to prevent dust and foreign matter from entering
when this terminal is not in use.
Remove the recorder and cuff from the patient, when the recorder is connected
to a printer or computer.
Data Transmission to a Printer
Caution
The recorder intensely consumes the battery power while connected to the
RS-232C cable. Disconnect the cable when not actually transferring data.
Maintain the power-on state while transmitting the data so that the data is not
damaged.
The optional RS-232C cable is required when connecting to a printer.
The printer (to print the data) must have a serial inter face and adapt to the
RS-232C protocol of the recorder.
Specifications for an adaptable printer
EIA RS-232C
Asynchronous, bi-directional, half duplex
Baud rate 9600 bps
Start bits 1 bit
Data bits 8 bits
Parity bit None
Stop bits 2 bits
X parameter Not used
ETX/ACK Not used
DSR Not used
Transmission
Code ASCII
Carriage return 0Dh
Next line 0Dh 0Ah
Command
Next page 0Ch 0Dh
Next page Automatic
Characters per line 72 min.
Printer parameters
Buffer size approx. 32Kbytes
