VCC-X Operator Interface SD
MODULAR SERVICE TOOL SD
11
Modular Service Tool Initialization
Modular Service Tool Initialization Screen and
Setup Screens
After connecting the Service Tool to the controller with the supplied
cable, press <ON>. The Initialization Screen will appear followed
by the Setup Screens as shown below. If there is no SD card in-
stalled, the second screen will display, “No SD Card Connected!
Powering Down!”
Initializing
Service Tool vX.XX
WattMaster Controls
1) Set Time & Date
2) Communications
NEXT) More Options
ESC) Exit Menu
3) Energy Saving
4) Update Software
NEXT) More Options
ESC) Exit Menu
NOTE: Once you press <ESC> while at the Setup Screens
shown above, you can access them again by pressing
<NEXT> or cycling power.
Initialization & Setting the Time & Date
Setting The Time & Date
The Modular Service Tool is equipped with a real time clock chip
allowing it to maintain the correct time. Once you have programmed
the correct time and date, the information is broadcast globally to
all controllers on the entire system.
NOTE: If you are in a time zone that has daylight savings,
you will need to manually adjust the time twice a year.
Programming the Time
From the Setup Screen shown below, press <1> on your keypad to
access the Set Time & Date Screens. (You may have to press <NEXT>
to access this screen).
1) Set Time & Date
2) Communications
NEXT) More Options
ESC) Exit Menu
Although the times are displayed on the Main Screen in a standard
12-hour format, you must program them using the 24-hour military
format. If you confi gured the VCC-X Controller to use its own
Internal Schedules, the Occupied/Unoccupied modes are calculated
on the basis of the current real time clock reading.
The two screens that follow will appear. To scroll through the fi elds,
press <> or
<ENTER>. In order to save a new value, you must
press <ENTER>.
Program Time/Date
Day (Sunday=0): X
Enter Hr. (0-23): XX
Enter Minutes : XX
Day - Enter the Day of the Week (0 to 6)
Sunday = 0
Hours (Hr) - Enter Hours in 24-Hour Military Format
(1700 = 5:00 PM)
Minutes - Enter the Minutes
(0 to 59)
Programming the Date
To scroll through the fi elds, press <> or <ENTER>. In order to
save a new value, you must press <ENTER>.
Program Time/Date
Month (1-12): XX
Day (1-31): XX
Year (00-99): XX
Month - Enter the Month (1 to 12)
Day - Enter the Day of the Month (1 to 31)
Year - Enter the current Year with two digits
(00 to 99)
When you have fi nished programming the time and date, press
<ESC> to return to the Setup Screen shown below.
1) Set Time & Date
2) Communications
NEXT) More Options
ESC) Exit Menu
