AAON SS1079 - RSMD Configuration Screens

VCC-X Operator Interface SD
RSM CONFIGURATION
67
RSMD Confi guration Screens
RSMD Main Confi guration Screen #1 -
Compressor Minimum Position
RSMD CONFIGURATION
Digital Compressor
Min Position: 11%
Enter the desired Digital Compressors’ minimum position. Range
is 11-50%. Default is 0%.
RSMD Main Confi guration Screen #2 -
Condenser Options
RSMD CONFIGURATION
Condenser Options
2 Cond per RSMD
USE < or > TO CHANGE
Enter the Condenser(s)’s Confi guration from the list below:
• 2 Condensers per RSMD
• 1 Condenser for 1 RSMD
• 1 Condenser for 2 RSMDs
• 1 Condenser for 3 RSMDs
• 2 Condenser for 2 RSMDs
RSMD #1-#4 Confi guration Screen #3 -
Compressor Option
RSM#1-4 Configuration
Compressor Option
DUAL
USE < or > TO CHANGE
Options are Dual or Single. Default is Dual.
RSMD #1-#4 Confi guration Screen #4 -
Compressor #1 Type
RSM#1-4 Configuration
Compressor #1 Type
MODULATING
USE < or > TO CHANGE
Options are Modulating or Fixed. Default is Modulating.
RSMD #1-#4 Confi guration Screen #5 -
Compressor #2 Type
RSM#1-4 Configuration
Compressor #2 Type
MODULATING
USE < or > TO CHANGE
Options are Modulating or Fixed. Default is Modulating.
RSMD #1-#4 Confi guration Screen #6 -
Refrigerant Circuit
RSM#1-4 Configuration
Refrigerant Circuit
Split
USE < or > TO CHANGE
Options are Split or Tandem. Default is Split.
RSMD #1-#4 Confi guration Screen #7 -
Fan Cycle Control
RSM#1-4 Configuration
Fan Cycle Control
No
USE < or > TO CHANGE
Options are Yes or No. Default is No.
RSMD #1-#4 Confi guration Screen #8 -
Fixed Condenser Fan
RSM#1-4 Configuration
Fixed Condenser Fan
No
USE < or > TO CHANGE
Options are Yes or No. Default is No.
