VCC-X Operator Interface SD
VCC-X STATUS
55
Screen #16 Current Outdoor Air Drybulb and Current
Outdoor Air Relative Humidity
Screen #17 Current Wetbulb Temperature and Current
Calculated Outdoor Air Dewpoint Temperature
Screen #18 Economizer Enabled or Disabled and Current
Economizer Open Percentage
Screen #19 Economizer Feedback Percentage for Title 24
Economizer
Screen #20 Economizer in IAQ Mode Yes/No and
Economizer Minimum Percentage
Screen #21 Current CO
2
Level, Minimum Setpoint, and
Maximum Setpoint
Screen #22 Outdoor Air CFM and Supply Air CFM
Screen #23 Return Air CFM and Exhaust Air CFM
Screen #24 Current Duct Static Pressure, Current Duct
Static Pressure Setpoint and Output Percentage
Screen #25 Current Building Pressure and Setpoint
Screen #26 Building Pressure Exhaust Fan Status and
Output Signal Percentage
Screen #27 Return Air Damper Signal & Return Air
Bypass Damper Signal
Screen #28 Reset Voltage Signal
Screens
#29-36 VCC-X Relays
Screens
#37-41 VCC-X EM1 Relays
Screens
#42-53 12 Relay Expansion Module Relays
Screens
#54-## Alarm Status Screens
VCC-X Status Screen Index
The available Status Screens for the VCC-X Controller are listed on
the next few pages by sequential screen number. The following is a
list of all the VCC-X Status Screens in numerical order with a brief
listing of the Status features available on each screen:
Screen #1 Date & Time
Screen #2 Application Type, Schedule Mode &
HVAC Mode
Screen #3 Controlling Temperature, Cooling & Heating
Setpoints
Screen #4 Space & Return Air Temperature &
Slide Adjust
Screen #5 Supply Air Temperature & Active Setpoint
Screen #6 Cooling Enabled: Yes/No
Screen #7 Cooling Outputs - Active Stages &
Mod Cooling Position
Screen #8 Heating Enabled Yes/No
Screen #9 Heating Outputs - Active Stages & Mod Heat
Position
Screen #10 MODGAS-X Enabled or Disabled and /
MODGAS-X Heating Output Signal
Screen #11 Current Space RH & Indoor RH Setpoint &
Return RH
Screen #12 MHGRV-X Enabled or Disabled and
MHGRV-X Reheat Valve Output Signal
Percentage
Screen #13 Preheat-X Enabled and Leaving Air
Temperature Setpoint
Screen #14 Current Preheat-X Leaving Air Temperature
and Entering Air Temperature
Screen #15 Current Preheat-X Modulating Position and
Active Stages
VCC-X Status Screens
