VCC-X SETPOINTS
VCC-X Operator Interface SD
54
Setpoint Screen #55 - Return Air Temperature
Sensor Calibration - Current and Offset
VCC-X Spts ID:#
Return Sensor Cal
Current: 0.0ºF
Offset.: 0.0ºF
If the Return Air Temperature Sensor is reading incorrectly, you can
use this option to enter an offset temperature to adjust the Sensor’s
Temperature. Line 3 will display the current Return Air Temperature
reading. Enter a positive Sensor Calibration value in Line 4 to raise
the Return Temperature Sensor reading or a negative value in Line
4 to lower the Sensor reading.
Description Minimum Default Maximum
Return Air Sensor
Calibration Offset
-100.0ºF
(-55.5ºC)
0.0ºF
(0ºC)
100.0ºF
(55.5ºC)
Setpoint Screen #56 - SAT Sensor Calibration
- Current and Offset
VCC-X Spts ID:#
SAT Sensor Cal
Current: 0.0ºF
Offset.: 0.0ºF
If the Supply Air Temperature Sensor is reading incorrectly, you can
use this option to enter an offset temperature to adjust the Sensor’s
Temperature. Line 3 will display the current Supply Air Temperature
Sensor reading. Enter a positive Sensor Calibration value in Line
4 to raise the Supply Air Temperature Sensor reading or a negative
value in Line 4 to lower the Sensor reading.
Description Minimum Default Maximum
Sensor Calibration SAT -100.0ºF
(-55.5ºC)
0.0ºF
(0ºC)
100.0ºF
(55.5ºC)
Setpoint Screen #57 - OAT Sensor Calibration
- Current and Offset
VCC-X Spts ID:#
OAT Sensor Cal
Current: 0.0ºF
Offset.: 0.0ºF
If the Outdoor Air Temperature Sensor is reading incorrectly, you
can use this option to enter an offset temperature to adjust the
Sensor’s Temperature. Line 3 will display the current Outdoor Air
Temperature Sensor Reading. Enter a positive Sensor Calibration
value in Line 4 to raise the Outdoor Air Temperature Sensor reading
or a negative value in Line 4 to lower the Sensor reading.
Description Minimum Default Maximum
OAT Sensor Calibration
Offset
-100.0ºF
(-55.5ºC)
0.0ºF
(0ºC)
100.0ºF
(55.5ºC)
Setpoint Screen #58 - CO
2
Sensor Calibration
- Current and Offset
VCC-X Spts ID:#
CO2 Sensor Cal
Current: 0ppm
Offset.: 0ppm
If the CO
2
Sensor is reading incorrectly, you can use this option
to enter an offset reading to adjust the Sensor’s Sensitivity. Line 3
will display the current CO
2
Sensor reading. Enter a positive Sensor
Calibration value in Line 4 to increase the CO
2
Sensor reading or a
negative value in Line 4 to lower the Sensor reading.
Description Minimum Default Maximum
Sensor Calibration CO
2
-500.0 PPM 0.0 PPM 500.0 PPM
VCC-X Setpoint Screens
