AAON VCCX-454 - BD-3 PI Inputs;Outputs Maps; Table 13: BD-3 PI Binary Inputs Wiring; Table 14: BD-3 PI Analog Inputs Wiring

32VCCX-454 Controller Technical Guide
INPUTS AND OUTPUTS
BD-3PI Inputs/Outputs Maps
BINARY INPUTS
PIN NAME
2 OCC/G
3 COOLING/Y
4 HEATING/W
5 DEHUM/DH
6 DISABLE HW/O
7 SPARE/E
ANALOG INPUTS
PIN NAME
8 SAT RESET
9 SAF SPEED
10 RAF SPEED
11 ECON POS
Table 13: BD-3PI Binary Inputs Wiring
Table 14: BD-3PI Analog Inputs Wiring
