ABB 4690 - Turbidity Sensor Connections

4690 Series
Turbidity systems 4 Electrical Connections
IM/4690–EN Rev. A 17
4.5 Turbidity Sensor Connections
Fig. 4.8 Turbidity Sensor Junction Box Connections
Emitter
Receiver
Wiper Unit
(Optional)
Blue
Red
Green
Yell ow
Screen
Screen
Red
Green
Blue
Screen
White
Black
Blue
Red
Green
Yellow
To
4690 /4695
Analyzer
Red
Screen
Blue
Link
