Installing the CEX-Bus Interconnection Unit BC810/TP857 Section 2 Installation

102 3BSE036351-510 A

Figure 33. The Power Source Connected to the Same PM864/BC810 Segment, see

Installing the CEX-Bus Interconnection Unit BC810/TP857 on page 97 and Power

Supply System on page 173.

CEX-Bus Units

SD8xx/SS8xx

BC810 CPU

CEX-Bus Units BC810 CPU
