Page #122 background imageLoading...
Page #122 background image
Installing the DriveBus Interface, CI858/TP858 Section 2 Installation
122 3BSE036351-510 A
Installing the DriveBus Interface, CI858/TP858
The CI858 is powered from the processor unit via the CEX bus and requires
therefore no additional external power source. The unit is mounted onto a horizontal
DIN rail.
Mount the unit onto the DIN-rail, see Mounting AC 800M Units onto DIN-Rail on
page 65, Installing the PM86x/TP830 Processor Unit in Single Configuration on
page 78 and CI858 and TP858 – DriveBus Interface on page 313.
Optical Connectors
The CI858 board connects to the drive system via three optical receiver/transmitter
pairs. HP/Agilent Technologies Versatile Link Series (HFBR family) optical
transmitter/receivers are used. Transmission speed of the optical fibres is 4 Mbit/s.
Table 16. Optical Connectors
Connector Designation Description
DriveBus TxD Transmit data
DriveBus RxD Receive data
I/O Bus TxD Transmit data
I/O Bus RxD Receive data
PC Tools TxD Transmit data
PC Tools RxD Receive data
Note that there is no unit redundancy for the CI858 unit.
