ABB AC 800M Manual

Communication Possibilities Section 3 Configuration
156 3BSE036351-510 A
Table 19. Interfaces Available on the CEX-Bus
Interface
Number of Interfaces on
CEX-Bus
Number of
ports per
Interface
Maximum of
each
interface
Maximum
total on
CEX-Bus
(1)(2)
(1) PM851/PM851A is restricted to a maximum of one CEX module.
CI851 (PROFIBUS DP) 12 12 1
CI852 (FOUNDATION Fieldbus H1) 12 1
CI853 (RS-232C) 12 2
CI854/CI854A
(PROFIBUS DP)
12 2
CI855
(Ethernet for MasterBus 300)
12 2
CI856 (S100) 12 1
CI857 (INSUM) 6 1
CI858 (DriveBus) 2 3
CI860 (FOUNDATION Fieldbus HSE) 12 1
CI862 (TRIO) 4 1
CI865 (Satt I/O) 4 1
CI867 (Modbus TCP) 12 2
CI868 (IEC 61850) 4 1
(3)
CI869 (AF100) 12 2
CI871 (PROFINET IO) 12 2
(3)
CI872 (MOD5) 4 8 3
CI873 (EtherNet/IP) 4 12 2
(3)
