ABB AC500-eCo V3 - General and Detailed Module Data

Parameter Value
PM5012 PM5032 PM5052 PM5072
Power supply 24 V DC
Connection of power supply Via removable 3-pin terminal
Current consumption from power supply (max.)
Transistor version 200 mA 340 mA 400 mA 420 mA
Relay version 200 mA 340 mA 400 mA -
Inrush current at nominal voltage On request
Required fuse On request
Max. power dissipation within the processor module
Transistor version On
request
On
request
On
request
On
request
Relay version On
request
On
request
On
request
-
Processor module interfaces RS485/RS232 (optional), Ethernet
- I/O bus
Weight
Transistor version 280 g 300 g 360 g
Relay version 330 g 350 g -
Mounting position Horizontal or vertical
Parameter Value
PM5012 PM5032 PM5052 PM5072
Global user program memory for (PROG/
DATA/WEB)
1 MB 2 MB 4 MB 8 MB
Thereof user program code / data
memory dynamically allocated
256 kB 512 kB 768 kB 1 MB
Thereof user web server memory for web
visualization max.
no web 1.5 MB 3.2 MB 7 MB
User data memory saved in FLASH 8 kB 32 kB 100 kB
VAR_RETAIN persistent 4 kB 16 kB 36 kB
%MB data 4 kB 16 kB 64 kB
Data buffering FRAM memory without battery
Real-time clock (RTC)
(no battery, supercap)
Optional
with
TA5131-
RTC
Built in
Min. retention time for RTC / accuracy in
s/day
On
request
On
request
On request On
request
Programming languages ● Instruction List (IL)
● Function Block Diagram (FBD)
● Ladder Diagram (LD)
● Sequential Function Chart (SFC)
● Structured Text (ST)
● Continuous Function Chart (CFC)
General data
Detailed data
Device specifications
Processor modules > PM50xx
